The ultrasonic transducer is the key component in an ultrasonic cleaning machine. The ultrasonic transducer is a device that generates sound above the range of human hearing, typically starting at 20 kHz, also known as ultrasonic vibrations.
An ultrasonic transducer consists of an active element, a backing and a radiating plate. Most ultrasonic cleaners use piezoelectric crystals as the active element. The piezoelectric crystal converts electrical energy to ultrasonic energy through the piezoelectric effect, in which the crystals change size and shape when they receive electrical energy.
The backing of an ultrasonic transducer is a thick material that absorbs the energy that radiates from the back of the piezoelectric crystal.
The radiating plate in an ultrasonic transducer works as a diaphragm that converts the ultrasonic energy to mechanical (pressure) waves in the fluid. Thus when the piezoelectric crystal receives pulses of electrical energy, the radiating plate responds with ultrasonic vibrations in the cleaning solution.
